Concrete floors, pads, walls, and soffits

Wedge Anchors

Screw Anchors

Rod Hangers (Internally Threaded)

Drop-ins & Equivalent*

*Shop drawing submittal or email confirmation required prior to use due to inability to confirm model once installed.

Concrete floors, pads, walls and soffits (Cont’d)

Cast-in Place Anchors

Epoxy

*Simpson ET-3G and UCAN FLO-ROK FR5 Max may be accepted but an ESR report is required.

Tapcon screw anchors do not have seismic certification or sufficient data for cracked concrete. They may, however, be accepted for light loads in certain applications:

• Surface wall mounting of equipment less than 100 lbs in normal importance projects (minimum four anchors)
• Small duct support where the load is less than 25 lb per anchor in normal importance projects
• VAV support where the load is less than 20 lb per anchor
• Installation of pendant fixtures where the load is less than 25 lbs per anchor and securement of safety chains/cables for fixtures installed in drop ceilings in normal importance projects

Minimum of 4” spacing between anchors. Screws to be 3/16” or 1/4”ø with a minimum embedment of 1-1/4” (screw to be a minimum of 1-1/2” long).

Grout-filled Hollow Block Walls

Wedge Anchors

Screw Anchors

Epoxy

*Simpson ET-3G may be accepted but an ESR report is required.

Concrete on Steel Deck

Wedge Anchors

Screw Anchors

Rod Hangers (Internally Threaded)

Epoxy

Drop-ins & Equivalent

Cast-in Place Anchors

Hollow Block Walls (no grout)

Screw Anchors

Epoxy

*Loads to be reviewed prior to approval for use. Tapcon and Dewalt Double may be accepted for light loads in certain applications.

Hollowcore

Rod Hangers (Internally Threaded)

Screw Anchors

Drop-ins & Equivalent

Wood

Rod Hangers (Internally Threaded)

Lag/Screw
